BESSEY TW16-20-10K Table Clamp, 8 x 4, T-bar, std pad, 16 mm

Description

BESSEY welding table clamps designed for 16 mm matrix tables are available in a wide range of choices for different needs including variable throat depth versions and accessories to complement the clamps. The TW16 series from BESSEY offers clamping elements with a fixed throat depth of 4 in. (100 mm) in. and a clamping capacity of approx. 8 in. (200 mm). For increased flexibility the TWV16 series adds 3 more clamps into the mix that have variable throat depth. The variable throat depth may be set to any distance that falls within the min-max range of the sliding arm. Both series are characterized by a tempered profiled rail and forged sliding arm for strength where you need it, as well as the option to choose between three handle variants. The versions with the high quality 2-component plastic handle and the T-bar handle have a smooth-running trapezoidal threaded spindle and replaceable pressure pads that require no tools to install. The lever handle variant has a positive locking ratchet mechanism for controlled, fast and vibration-proof clamping. Many accessories are available, such as V-blocks, variable risers and assorted adapters that enable the use of toggle clamps on matrix tables with 16 mm holes. There are also 4 different adapters that allow use of the TW16 series clamps on woodworking benches with 3/4 inch, 20mm, 1 inch & 30mm bench dog holes. BESSEY. Simply better.

For use on matrix tables with 16 mm holes
Versatile, making changes to a set up is very easy
Fast application of clamping force
Patented rail profile
Engineered for demanding applications
Choose between fixed or variable throat depth versions
Three choices of handle, T-Bar, 2K or Lever
Other adaptors available are the TW16AW25 for 1 inch, TW16AW20 for 20 mm and TW16AW30 for 30 mm diameter bench dog holes
Welding table clamp, fixed throat depth TW
Tempered profile and sliding arm for strong, dependable, clamping. Available with: high quality 2-component plastic handle; T-Bar with rounded ends (each with smooth-running ACME threaded spindle and tool free pressure plate replacement); or lever handle with an ratcheting mechanism for controlled, fast and vibration-proof clamping.

Specifications:

Jaw Width: 1.25 Inches.
Throat Depth: 4 Inches.
Nominal Clamping Capacity: 8 Inches.
Clamping Force: 650 LBS.
Rail Dimensions: 55/64 Inches x 21/64 Inches.
Clamping Screw Diameter: 0.625 Inches.
Handle Length: 3.858 Inches.
