DEWALT 50238N-PWR CSI Pins, 1/2" L, 8mm Head, .145" D, Box 100, Collated

Description

CSI Spiral Drive Pins are designed for permanently fastening a fixture to concrete, concrete over steel deck, concrete masonry walls and A36 or A572 / A992 structural steel. The fasteners are manufactured with an 8mm head and 0.157" diameter shank in various lengths; a 0.145" diameter tapered shank with 1/2-inch length is also available. A spiral knurled shank design provides consistent optimized performance in steel base materials. For single fasteners, a plastic washer is mounted on the pin shank to retain the drive pin in the barrel of the tool and provide centered guidance during the driving operation. The fasteners are also available in collated strips.
Shank diameter: 0.145"
Shank length: 1/2"
Shank type: Tapered

APPLICATIONS:
Attaching light gauge steel to concrete, concrete over steel deck, concrete masonry or steel
Attaching wood members to concrete, concrete masonry or steel
Attaching accessories, fixtures and components to concrete, concrete over steel deck, concrete masonry or steel
Sill plate and perimeter anchorage
