Description
7-1/4" Cordless Rear Handle Circular Saw with Brushless Motor
THE WORLD'S FIRST CORDLESS REAR-HANDLE CIRCULAR SAW! 558 Cuts In 2" x 4" Material Using 5.0 Ah Batteries!!
Cutting Capacity of 2-9/16" (65 mm)
High performance for heavy-duty cutting applications
Automatic torque Drive Technology (ADT) feature adjusts the torque and speed according to the load condition, enabling rapid movement between high speed and high torque applications
LED charge level indicator displays approximate remaining battery power
Lightweight design with magnesium baseplate and blade case
Enlarged depth scale with rubberized lever for maximum operator convenience and accuracy
Large integrated tool hanger provides convenience on the jobsite and fits 4" x 4" material
Two-stage safety trigger switch prevents accidental start up
Electric brake stops blade 3-5 seconds after trigger is released for increased operator safety
Soft start feature gradually increases speed to eliminate start up shock
Brushless DC motor with high power to weight and size ratio
Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing / production applications
Battery protection system provides over-discharge, temperature and current protection for enhanced performance, battery cycle life and overall battery life
eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for optimal performance in extreme conditions
Bevel capacity of 0o - 53o with positive stop at 22.5o and 45o
Ergonomic soft rubber grip design for vibration absorption and comfortable operation
Items Included: Tool Only. Batteries and Charger Sold Separately. 7-1/4" C.T. Blade 24T (1 Ea. A-94530-10), Offset Wrench 13 (782016-4)
Specifications
Battery Capacities Two 18V Li-Ion
Blade Diameter 7-1/4" (185 mm)
Arbor 5/8" (15.88 mm)
Maximum Cutting Depth:
0° 2-9/16" (65 mm)
45o 1-3/4" (45 mm)
53o 1-1/2" (38 mm)
No Load Speed 5,100 RPM
Vibration Level (Unavailable)
Noise Level (Unavailable)
Overall Length 17-1/2" (446 mm)
Net Weight 9.5 lbs (4.3 kg)
Reviews
There are no reviews yet.
