Description
3-1/4" Planer
Lightweight Design For Easy Surface Planing
- Base Plate Foot protects materials and blade from damage
- Single Chamfering Groove enables quick and easy chamfering of corners
- Depth Adjustment Knob with Click Stops for precision planing applications
- Lock-On Button enables easy continuous operation and can be operated from left or right side
- Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Items Included: 3-1/4" Double Edged Mini Planer Blades (D-16966), Blade Gauge Assembly (191C19-9), Socket Wrench 9 (782209-3), Guide Rule (195055-9)
Specifications
Maximum Capacities:
Planing Width: 3-1/4" (82 mm)
Planing Depth: 0-3/32" (0 - 2.5 mm)
Shiplapping: 0 - 11/32" (0 - 9 mm)
No Load Speed: 17,000 RPM
AMPS (120V): 6.5 A
Vibration Level: 2.5 m/s2
Noise Level: 89 dB(A)
Overall Length: 11-1/4" (285 mm)
Net Weight: 5.7 lbs (2.6 kg)
