SPECTRA LL300S-2 Rotary Laser Pkg w/HL450 Receiver, GR152 Rod, Q104025 Tripod

Description

Spectra Precision LL300S-2 Laser Complete Package w/ HL450 Receiver

SPECTRA LL300S-2 laser package with HL450 Receiver
Includes: Grade Rod INCHES and Aluminum Tripod with System Case

Medium-range, highly accurate leveling solution
The Spectra Precision® LL300S-2 is a ruggedized, fully automatic self-leveling Laser Level for all general concrete and site preparation applications. With the addition of the arrow buttons on the transmitter, grade matching and single axis manual slope can be performed whilst the other axis remains self leveled. A standout feature of this LL300S-2 package is the HL450 Receiver. This rugged Receiver is best in class and features a Large 4-Inch reception height. With this Larger reception height you get more data back from the laser allowing better accuracy and faster readings.

Spectra Precision LL300S-2 Laser APPLICATIONS
General elevation control
Checking and setting elevations for small to medium job sites
Leveling forms and footers
Estimating cut and fills
Excavations
Basic slopes for driveways and ramps

Spectra Precision LL300S-2 Laser KEY FEATURES
Automatic self-leveling
Accuracy 1/16 inch @ 100 ft
Working range of 2,600 ft diameter
Simple keypad for easy grade matching
Height of Instrument Alert - unit stops rotating when jarred to avoid erroneous readings
Long range Radio remote control (optional)
LL300S-27 Complete kit available and fits in one case with tripod and INCHES grade rod
Extremely durable and portable

Spectra Precision LL300N-2 Laser BENEFITS
Complete leveling crew in a case Model LL300S-2 includes carrying case securely holds all components, tripod and grade rod
Easy to transport, easy to carry, easy to store
Highly durable construction
Superior drop and weather protection.
Fully automatic self-leveling
Superior drop and weather protection.
Energy-efficient design offers long battery life
Extremely versatile with single-axis manual slope
Cross-axis self-leveling allows for grade matching on the job site.
Highly durable construction enables the LL300S to survive a drop up to 3 feet onto concrete
Optional Radio remote control offers access to all laser function from every jobsite place and single person manual slope

Spectra Precision LL300S Red Beam Laser SPECIFICATIONS
Laser Source: red diode 650nm, Class 2, <3,4mW
Laser Accuracy: ±1/16-inch at 100-feet
Operating Range: 2,600 foot diameter
(optional) Remote Control Operating Range: 330 foot
Compensation Method: Electronic Self-Leveling
Drop Height onto Concrete Performance: 3 foot
Single Axis Manual Slope: Yes (with self-leveling mode on the second axis)
Out of level Warning: Rotor stops, red out-of-level HI/MAN-LED flashes
Power Source: 4 x D-Cell Alkaline Batteries
Battery Life: Alkaline - 60 hours
Battery Status LED: Flashing red LED
Rotation Speed: 600 RPM
Storage Temperature: -4°F to 158°F
Operating Temperature: -4°F to 122°F
Dust and Waterproof: Yes - IP66
Tripod Attachments: 5/8 x 11 horizontally and vertically
Weight: 5.9 lbs
Size: 10.7 L x 7.7 W x 7.9 H inch
