TOPRING 20.444 Coupler AUTOMAX (1/4 IND) 1/4(F)NPT

Description

Technical specifications and certifications
• Thread: 1/4 (F) NPT
• Maximum Working Pressure: 250 PSI
• Working Temperature: -40 to 107 °C
• Airflow: 37 SCFM at 100 PSI inlet with 10 PSI pressure drop

Material(s):
• Body: Brass
• Backnut: Zinc plated steel
• Sleeve: Zinc plated steel
• Valve Spring: Stainless steel
• Valve: Brass
• Locking Mechanism: Hardened steel and zinc plated
• Seals: Nitrile rubber

Features and benefits
• Accept 1/4 INDUSTRIAL interchange plugs (A-A-59439)
• Automatic push-to-connect operation
• Proven and positive connection using pin lock mechanism

Applications
• Compressed air distribution systems
• Air tools
