TOPRING 55.120 Gauge 1-1/2 - 1/8NPT CBM 0-160

Description

• Diameter: 1-1/2 in
• CBM: 1/8 NPT
• Pressure Range: 0-160 PSI
• Dual scale in PSI (black) and in kPa (red)
• Working Temperature: -18 to 60 °C
• Accuracy: ± 2,5 % of the full scale

Material(s):
• Housing: Black painted steel
• Crystal: Acrylic
• Bourdon Tube: Phosphorous bronze
• Movement: Brass and nylon with highly polished bearing surfaces
• Connection: Brass

Features and benefits
• Stem and connection are machined from a single piece of brass
• Precision movement provides accurate readings
• TOPRING standard dry pressure gauges are high quality pressure gauges designed to provide reliable service in applications and environments where the atmospheric and substances used do not have corrosive effects on brass
• Pressure gauges with CRN numbers available upon request
• Calibration certifications available upon request
